ArchiMate Extrator for Pega

Generate enterprise architecture models from your Pega apps

By using or submitting listings via the Pega Marketplace, you agree to our Terms of Use.

4:43
Video Player is loading.
Current Time 0:00
Duration 0:00
Loaded: 0%
Stream Type LIVE
Remaining Time 0:00

1x
  • Chapters
  • descriptions off, selected
  • captions off, selected

      Overview

      The ArchiMate extractor component for Pega allows you to extract an “ArchiMate Open Exchange File” based on the configuration of your Pega application.

      You can upload the component to your application using the component management feature inside of the your Application rule or by uploading the zip file like any other import and adding it to the built on component list.

      Key Features

      The extrator will go through the application and its configuration and extract the following information and create views:

      • Case types
        • Stages
        • Processes
        • Roles
        • Data Objects
      • Data Objects
        • Relations
      • Channels
      • Application stack
      Note:
      Additional relations available in the Archimate model are not immediately visible in the standard Pega views. You can view the XML file in Archi or any ArchiMate based tool by simply importing it.

      Resources

      Implementation Guide

      logo

      Version

      01.01.01

      Compatible with

      Pega Platform 8.8 8.7 8.6 8.5 8.4 8.3 8.2 8.1

      Product Owner

      Jeroen Geerdink

      Last updated

      March 8, 2023

      Product Capability

      Case Management System Administration
